Cables and Connections:
The Rocktron PowerTap comes with 11 connector
cables to supply power to your pedals. On the front
panel of the PowerTap you will find 8 output jacks.
Using the included jumper cables you can power a va-
riety of pedals. The polarity is TIP “NEGATIVE” and
BARREL “POSTIVE”. Most pedals are TIP Nega-
tive and BARREL Positive, however, it is important
you first determine what your pedals require before
using these cables.
The 11 cables included are:
6 BLACK cables are 5.5 x 2.1mm (jack), Tip Nega-
tive, Barrel Postive
1 RED cable is 5.5 x 2.5mm (jack). This is an AC
Cable and should only be used with AC Output on the
PowerTAP. Do not use this cable with DC (Battery
Powered) pedals as it will damage the pedal and/or the
PowerTAP.
1 BLACK 3.5mm (1/8”) mini plug cable to be used
with older stomp boxes requiring this kind of jack.
This cable is TIP POSTIVE. Check your pedal’s
power requirements before using this cable
