Descriptions continued.........
DC 9VOLT OUTPUTS - These 5 outputs
provide 9V DC power or 12V DC power. Before
plugging in any pedals to these jacks, first
determine what power is required by your pedal.
Then use the DIP Switches located on the back of
the PowerTAP (see point 8 for more information)
to select DC9V or DC12V. Use the included
cables to plug in your pedals.
DC SAG 4V-9V - These 2 outputs provide either
9V power or variable 4V-9V power. The DIP
switchs on the back panel of the PowerTAP
(see point 8 for more information) determine if
these jacks supply 9V power or a variable power
from 4V-9V. When selected, the 4V-9V power
can be adjusted using a small screw driver (not
included). Turning the white screws controls the
DC SAG which will allows you to emulate the
“dying battery” effect.
AC9 VOLT - CAUTION!!!!! This output
provides AC 9V POWER. Use caution before
plugging into this jack. First determine if your
pedal needs DC or AC power before using this
jack.
