Portable Winch Gas-powered portable capstan winch PCW3000 User Manual

Page 3

Introduction

Portable Winch Co. wishes to thank you for purchasing a Portable Capstan Winch

. This

manual was written to help you make the best use of your new winch and to use it in the most
secure way. R

EAD IT CAREFULLY BEFORE USING THE WINCH

. For any problems or questions please

refer to an authorized Portable Winch Co. dealer or contact us directly.

1.0 Safety guidelines

This Portable Capstan Winche

is designed to pull non-rolling objects, usually at a plus or

minus 45 degree angle from the horizontal. The use of a pulling device implies serious risks of
injuries, property damage or even death. Do not underestimate its potential danger.

1.1 Safety messages

Your safety and the safety of others are very important. You will find important safety messages
in this manual. Read them carefully.

These security messages are warning you of potential injuries to either you or others. Every

safety message is preceded by a warning symbol

and one of the following terms:

DANGER, WARNING or CAUTION.

These indicator words mean:

You WILL be MORTALLY or SEVERELY INJURED if you do not follow

these instructions.

You COULD be MORTALLY or SEVERELY INJURED if you do not follow

these instructions.

You COULD be INJURED if you do not

follow these instructions.

1.2 Label

1.2.1 Serial number and warning label

The serial number and warning label is positioned on the right
side of the winch housing. See the meaning of all four icons in
the figure 1.

Read this instruction manual and Honda engine user’s
manual prior to using the winch.

2. Only use low-stretch rope. Minimum diameter: 10 mm

(3/8’’). Maximum diameter: 12 mm (1/2’’).

3. Never place your hands near the drum while the engine

is running.

4. Never use the winch for lifting people.
