Portable Winch Gas-powered portable capstan winch PCW3000 User Manual
Page 21
21
ITEM
NO.
PART NUMBER
DESCRIPTION
QTY
1
31-0010
HCS 1/2-13 X 6 - GR5 - ZN
1
2
35-0004
FLAT WASHER 1/2 - ZN
4
3
10-0098
BUSHING FOR SAFETY HOOK
2
4
PCA-1281
SAFETY HOOK 3/4 TON
2
5
32-0008
HEX FLANGE SERRATED BOLT M8-1.25 X 16MM - ZN
2
6
10-0135
ROPE EXIT HOOK
1
7
32-0004
BHCS M6-1 X 16 MM - SS
9
8
10-0131
ROPE GUIDE FOR CAPSTAN DRUM 76 MM
1
9
10-0137
WINCH HANDLE (PCW3000)
1
10
44-0002
THROTTLE LEVER
1
11
10-0134
THROTTLE CABLE ASSEMBLY
1
12
33-0005
NYLON LOCKNUT 1/2-13 - ZN
1
13
32-0009
SHCS M5-0.8 X 10MM
1
14
45-0002
ON/OFF SWITCH (PCW3000)
1
15
10-0130
GUARD PLATE (PCW3000)
1
16
39-0007
METAL SCREW #10 X 1/2 - ZN
4
17
10-0136
ROPE ENTRY HOOK
1
18
10-0129
CAPSTAN DRUM 76 MM
1
43-0023
SHAFT KEY FOR CAPSTAN DRUM 76 MM
1
19
10-0102
DRUM RETAINING WASHER
1
20
44-0001
UNIVERSAL SERIAL NUMBER & WARNING LABEL
1
21
44-0025
ROPE INSTALLATION LABEL PCW3000
1
22
44-0023
DECIBEL WARNING 93 dB LABEL
1
5.6 Technical data
Engine: 4-stroke all positions Honda GX-35 cc
Maximum pulling force (single line): 700 kg (1550 lb)
Speed: 8 m/min (26 ft/min)
Capstan drum: 76 mm (3’’) diameter
o Up to 4 wraps of 10 mm
(3/8’’) rope
Gear box: Aluminum alloy; Gear ratio 200:1
Unit weight: 9,5 kg (20 lb)
Dimensions (overall): Length 35 cm x Width 28,9 cm x Height 26,1 cm (13-
3/4’’ x 11-
3/8’’ x 10-1/4’’)
Rope: Double braided polyester (not included)
– Unlimited rope length
o M
inimum diameter: 10 mm (3/8’’)
o Maximum diameter: 12-
13 mm (1/2’’)
