MAKE SURE THE ANCHOR

ING VEHICLE’S HAND BRAKE IS ON AND

WORKING PROPERLY. POSITION BLOCKS BEHIND THE WHEELS TO PREVENT ROLL
BACK.

3.3.5 Using the tree/pole mount with anchor strap (PCA-1263)

The tree/pole mount is intended to use with either the winch support plate (PCA-1268) or the
vertical pull winch support (PCA-1264). Therefore, you must first install the tree/pole mount. To
do this, follow these steps:

1) Figure 1:

Place the tree/pole mount at the base of the tree or pole. Insert the sling’s hook

into the anchor point on the left

; then feed the sling’s end through the ratchet system;

2) Figure 2: Slide the whole set-up upward to the desired height and remove the supplied

wrench;

3) Figure 3: Tighten the sling with the wrench while making sure the rubber pads are

properly positioned. The pads should offer maximum contact surface with the tree or pole.
