- 5 -
PTM Installation in a 4848
Primary Temperature Module (continued)
Press “SET” and release
Operation
Mode
Select type/value Comment
At OFF Auto Tuning ON/OFF
PID0 0 The 0 th PID Parameter
SV 0 The 0 th SV
P0 11.8 Proportional control
I0 375 Integral control
D0 93 Derivative control
IoF0 0 Integral value offset
HtPd 5 Heat cycle control
HcPd 5 Cool cycle control
CoEF 10 1 & 2 value output group during dual loop output
control
dEAd 0 Dead band
tPoF 0 Inaccuracy adjustment
