Parr Instrument 5500 HPCL User Manual
Page 7
7
12. Check set screw of the coupling on drive adapter and tighten if necessary. With the correct
installation of all parts there should be a gap between the coupling halves.
13. Finished assembly should look similar to Picture 8 depending on existing reactor head
configuration.
Coupling half attached to
drive adapter of magnetic
drive assembly
Align top half of
coupling with the
blue spider hub
Blue Spider Hub
Picture 7
