11. Screw existing motor onto the top cap of retro-fit assembly, aligning the coupling half on the
motor with the blue spider hub on the coupling that is attached to the magnetic drive assembly
(see Picture 7). Continue to screw in the motor until it is snug against the top cap.
Set Screw
Existing 1/50HP
Motor
3083HC Coupling Half
must be flush with motor
shaft as shown
Picture 6
