Congratulations on your purchase of the fi nest ultra micro RC Corsair available. If you’ve fl own
the larger ParkZone Corsair, you’ll fi nd this one fl ies sport aerobatics every bit as well, only in a
much smaller space. Before you take the fi rst fl ight, though, please take time to read through
this manual. It has important pre-fl ight information that will help ensure your fi rst fl ight is a
great one.
To register your product online, go to www.parkzone.com
First Flight Preparation
• Remove and inspect contents
• Install batteries into battery charger
• Begin charging the fl ight battery
• Install batteries into the included
transmitter (RTF ONLY)
• Install fully charged fl ight battery into
aircraft
• Bind the receiver to a transmitter
(BNF ONLY)
• Perform the Control Direction Test with the
transmitter
• Adjust fl ight controls and transmitter
• Adjust battery for center of gravity (CG)
• Perform a radio system Range Check
• Find a safe and open area
• Plan fl ight for fl ying fi eld conditions
Note: For Decal Application Options refer to
the back of this manual.
Table of Contents
F4U Corsair Specifi cations
Wingspan 15.9 in (405mm)
Length 12.8 in (326mm)
Weight 1.47 oz (41.8 g)
F4U Corsair Features
Bind-N-Fly
Version
Ready-to -Fly
Version
Onboard Electronics
Spektrum AR6400 Receiver/Servos/
ESC/ 2 SPMAS2000L Servos
Installed Installed
Battery
150mAh 3.7V 12C Li-Po
Included Included
Charger
1S 3.7V Li-Po Battery Charger
Included Included
Transmitter
DSM 4-Channel Transmitter, 2.4GHz
Sold Separately Included
EN
First Flight Preparation ...................................... 3
Charging the Battery .......................................... 4
Battery Warnings ................................................. 5
Low Voltage Cutoff (LVC) .................................. 5
Transmitter and Receiver Binding ................. 6
Before Flight .......................................................... 6
Installing Transmitter Battery .......................... 6
Transmitter Control............................................. 7
Digital Trims ........................................................... 7
Dual Rate Function ............................................. 7
Control Direction Test ........................................ 8
Reverse Controls .................................................. 9
Control Centering ............................................... 9
Control Rates .......................................................10
Settings for Control Horns .............................10
Installing Flight Battery ...................................10
Adjusting Center of Gravity (CG) ..................11
Removing and Installing Landing Gear .....11
Propeller and Propeller
Shaft Maintenance ............................................12
Removing and Installing the Propeller ......12 Remove Propeller Shaft...................................12
Installing Propeller Shaft ................................12
Flying Tips and Repairs ....................................13
Additional Safety Precautions
and Warnings ......................................................14
Maintenance After Flying ...............................14
Troubleshooting Guide ...................................14
Warranty and Repair Policy ............................16
Warranty and Service Information ..............17
FCC Information .................................................17
Compliance Information for
the European Union .........................................17
Declaration of Conformity ............................18
Instructions for disposal of WEEE
by users in the European Union ...................18
Replacement Parts ............................................70
Optional Parts and Accessories ....................71
Decal Application (Option 1) .........................72
Decal Application (Option 2) .........................73
Parts Contact Information ..............................74
