11
To Remove:
1. Lift the end of the landing gear wire above
the
stop.
2. Gently pull the landing gear toward the
center of the wing and away from the clips.
To Install:
1. Gently slide the landing gear into the plastic
clips on the bottom of the wing.
2. The landing gear is installed when the end
of the landing gear wire is inside the stop.
The CG location is 28mm back from leading
edge of the wing at the root. This CG location
has been determined with the included 1S
150mAh 3.7V Li-Po battery installed in the
front of the battery cavity.
Adjusting Center of Gravity (CG)
Note: The battery cavity is oversized to allow for Center of Gravity adjustment. Start by
placing the battery in the front of the cavity and adjust as necessary.
EN
28mm
Removing and Installing Landing Gear
Note: Install left and right gear with the vertical strut of the landing gear toward the front of
the wing. Install the bent wire of each strut fully inside each mount.
