Welcome to an exciting new world of fl ying possibilities. Bedrooms, conference rooms, garages,
basements, break rooms, offi
ces–all can be transformed into aerial RC playgrounds with the Ultra
Micro Series Mini Vapor®. Its small size, negligible mass and proportional 3-channel control will let you
confi dently fl y almost anywhere indoors without worrying about damage to it or the furniture.
Before you start exploring your new found fl ying opportunities, however, you must take some time to
read this manual. It contains important information about some of the aircraft’s wind limitations, DSM2®/
DSMX® technology, battery charging and much more. You’ll also fi nd a handy troubleshooting guide. It’s
all here to make sure your fi rst fl ight, and every one after, is the best it can be.
Table of Contents
Charging the Battery ...................................................4
Charging Warnings .......................................................5
Installing Transmitter Batteries .................................6
Transmitter and Receiver Binding ............................6
Installing the Flight Battery and Arming the ESC 7
Prefl ight Checklist ........................................................7
Digital Trims ...................................................................8
Dual Rate Function .......................................................8
Transmitter Control ......................................................8
Control Direction Test ..................................................9
Reverse Controls ........................................................ 10
Control Centering ..................................................... 10
Settings for Control Horns ....................................... 10
Control Rates .............................................................. 11 Adjusting Center of Gravity (CG) ............................ 11
Motor Service ............................................................. 12
Flying Tips and Repairs ............................................. 13
Additional Safety Precautions and Warnings ..... 14
Post Flight Checklist .................................................. 14
Troubleshooting Guide ............................................ 15
Limited Warranty ....................................................... 16
Warranty and Service Information ........................ 18
FCC Information ......................................................... 19
Compliance Information for the European Union 19
Replacement Parts .................................................... 72
Optional Parts and Accessories .............................. 73
Parts Contact Information ....................................... 73
Specifi cations
To register your product online, go to www.parkzone.com
Box Contents
Includes
Installed Installed 6mm Brushed Motor
Installed Installed
Super Lite DSMX®
RX/ESC/Servos
(PKZU1252)
Included Included
Battery: 30mAh 3.7
25C Li-Po
Included Included
Charger: 1S 3.7V Li-Po
Battery Charger
Included
Needed to
Complete
DSM2/DSMX 4-Channel
Transmitter
11.8 in (299mm)
.31 oz (8.7 g)
8.7 in (220mm)
