SPECIFICATIONS

GENERAL SPECIFICATIONS

OUTPUT SPECIFICATIONS

Input Voltage

2

36~75V

Voltage Accuracy

Typical ±1.5%

Switching Frequency

Line Regulation

Typical (3.3V)

350KHz

Typical ±0.5%

Isolation Voltage

In/Out 1500V Load Regulation

Typical ±1.5%

Isolation Capacitance Typical 1500

pF

Ripple & Noise

Typical 50

mV

Isolation Resistance Minimum 10M

Ohms

Current Limits

Typical 140%

MTBF

Over Voltage

Bellcore (3.3V)

TBD

Typical 135%

Size

Voltage Trim

(2.28” Ч1.45” Ч0.38”)

57.9 x 36.8 x 9.7 mm

For Vout2

±10%

PART NUMBERING SYSTEM

Q

48

D

M

3R3

12

N

N

F

A

Product

Type

Input

Voltage

Number of

Outputs

Product

Series

Output

Voltage 1

Output

ON/OFF

Logic

Pin

Length

Option

Code

Voltage 2

Q - Quarter

Brick

48V

D - Dual Output

M - 75W
Platform

3R3 - 3.3V

12 - 1.2V

N - Negative

N - 0.150”

A - Standard

Functions

F - RoHS 6/6

R - 0.170”

P - Positive

(Lead Free)

MODEL LIST

OUTPUT

*

MODEL NAME

INPUT

EFF @ Full Load

Q48DM3R312NN A

36V~75V

2.4A

3.3V/12A

1.2V/25A

88.5%

*

Note: Total output power should not exceed 75 watts and maximum output current for high output is 12A, for low output is 25A.


MECHANICAL DRAWING

CONTACT:

www.delta.com.tw/dcdc

USA:

Europe:

Asia & the rest of world:

Telephone:

Telephone: +41 31 998 53 11

Telephone: +886 3 4526107 ext 6220

East Coast: (888) 335 8201

Fax: +41 31 998 53 53

Fax: +886 3 4513485

West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:

[email protected]

Email:

[email protected]

Email:

[email protected]

WARRANTY

Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon request from
Delta.

Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor
for any infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
