7
Taking a Tour of the Flybook V5
2
Rear View
1. RJ-11 modem jack
– Connect a phone line to this jack to use the internal
modem.
2. Ethernet connector
– Connect the computer to your home or office network
(LAN) with the Ethernet connector.
3. Monitor (VGA) connector
– Connect an external display or projector to the moni-
tor connector.
4. TV connector
– Connect a TV to this connector to use the TV as an
external display.
5. Headphone jack
– Connect headphones or external speakers to the
headphone jack.
6 5 2 1 3 4
8 9 10 7
