MAN 650066:E

23

Oil pressure sensor test (

test)

This menu will allow you to check the voltage the control box is reading from the pressure

sensor. This can be used for a diagnostic tool if you are having trouble or feel that the reading
is incorrect. For the Dakota Digital SEN-03-8, 0-100 psi sensor, the voltage increases with
pressure. At 0 psi, the voltage should be close to 0.5V at 100 psi the voltage should be close to
4.5V.
• When

“test” is displayed, press and hold SW1 until you get “ - ”

• Release SW1 and the current voltage from the pressure sensor will be displayed on the

speedometer and “V OIL” is displayed on the odometer readout.

• Press and release SW1 to scroll through the next sensor input if you wish “R FUEL”

“R temp” “v oil”

• Once complete, hold SW1 until “ - ” “DONE” is displayed.

• Release the switch to go onto the next sub-menu item.

Exit oil pressure setup (

done)

This will allow you to exit the oil pressure setup and go on to the next setup menu.

• When

“Set done” is displayed, press and hold SW1 until you get “ - DONE ”

• Release the switch to go onto the next menu.

FUEL SETUP

The control box can read seven common fuel level sender resistance values. If your

sender is not shown in the table below, the system can be programmed to read a custom
sender. The table below shows the seven pre-programmed senders and their respective empty
and full resistance values.

Sender type

Menu

Empty R

Full R

GM 0-30 ohm (mid 60’s-earlier)

GM 30

0 ohms

30 ohms

GM 0-90 ohm (mid 60’s-late 90’s)

GM 90

0 ohms

90 ohms

GM 40-250 ohm (late 90’s-later)

GM 250

40 ohms

249 ohms

FORD 73-10 ohm (earlier -late 80’s)

F 10

73 ohms

10 ohms

FORD 20-150 ohm (late 80’s-later)

F 150

20 ohms

150 ohms

VDO 10-180 ohm

V 180

10 ohms

180 ohms

SW/SUN 240-33

SW 33

240 ohms

33 ohms

User programmed

CUSTOM

User settable User settable

• Press and hold SW1 while turning the key on. Release the switch.

• Press and release SW1 to get to the “FUEL” setup menu.
• Press and hold the switch until “-- fuel” is displayed to enter the fuel setup menus, then

release SW1.

• Now you can press and release the switch to scroll through the fuel sub-menus, “SENDER”

“custom” “test” “DONE”. When you get to the desired sub-menu, press and hold the switch
to select it.
