4 handle – Livorsi Plantinum Series User Manual

Page 8

background image

5 17/32"

FLANGE

4 7/8"

CUTOUT

4 15/16"

4 HANDLE

6 1/2"

CUTOUT

9/64" PILOT HOLE

FOR #10 SCREW (4)

7 3/4" FLANGE

7 11/64"
