7 9/16"

FLANGE

6 7/8"

CUTOUT

6 15/16"

6 7/8"

CUTOUT

6 HANDLE

6 1/2"

CUTOUT

9/64" PILOT HOLE

FOR #10 SCREW (4)

7 3/4" FLANGE
