Livorsi Marine, Inc. Platinum Series Installation Instructions Rev C 2 of 6
715 Center Street Grayslake IL 60030
P: 847-752-2700
F: 847-752-2415
Shift lever in reverse
position will close
highlighted circuit.
Throttle controlled by 0-5 volt potentiometer
programmable to customer’s specifications.
Control will be labeled for forward direction,
DO NOT reverse.
Single Switch function associated with highlighted harness.
Red = +12 vdc
Green = Down
Blue = Up
Plantinum Series Control Installation Instructions- Full Electronic Control
Deutsch plug connects to
the engine’s controller
FORWARD
