Lingenfelter Katech Cadillac CTS-V Stainless Steel Short Throw Shifter - Manual (Page 4)

Created on 11/30/2007 Page 4 of 10
10) Using a flat blade tool, release the right side shift
control rod pin retainer.
11) Remove the shift control rod pin.
12) Using a flat blade tool, release the left side shift
control rod pin retainer. The graphic shows the
transmission removed for clarity.
13) Remove the shift control rod pin.
14) Using a flat blade tool, release the center shift
control rod pin retainer. The graphic shows the
transmission removed for clarity.
15) Remove the center shift control rod pin retainer.
16) Remove the shift control assembly from the
transmission. Remove the shift control assembly
from the vehicle.
17) After noting the orientation of the horizontal shift
rod, remove the shift rod from the shift lever.
