Remove the 3/8” barbed plastic quick couple from the accordion section of your stock air intake system (see
picture). Install the quick coupler into the silicone hump hose by pushing the barbed side into the 3/8” nipple on
the hump hose. Do not use lubricant.
Slide 90-110 mm clamps on either side of the hump hose
and then slide the hump hose onto the MAF housing.
Rotate the hump hose such that the nipple will locate
just above the throttle body motor (roughly 10 o’clock
position, see pictures). Rotate the MAF sensor assembly
such that the logo on the sensor housing is at the top and
lines up with the logo on the air-bridge.
Rotate the assembly to engage the hump hose over
the throttle body. Make sure the bottom of the hose is
properly located over the throttle body.
Push the “hump” portion of the hose towards the throttle
body while tightening the clamp on the throttle body.
Tighten the next two clamps (in order going away from
the throttle body), making sure the hoses are fully
engaged.
