Page 24.
88. Install the inlet air pressure sensor onto
the front cover. Using a 10 mm socket, torque
the fastener to 10 Nm (89 lb-in). Plug the
electrical connector back into inlet air pressure
sensor.
87. Install the purge solenoid onto the front
cover. Using a 10 mm socket, torque the
fastener to 10 Nm (89 lb-in).
86. Install the boost control solenoid bracket
assembly onto the front cover. Using a 10 mm
socket, torque the fastener to 10 Nm (89 lb-in).
Replace all vacuum hoses.
NOTE: Refer to the diagram on page 38 for the
vacuum routing diagram.
85. Tighten the set screw so that it barely
touches the stop plate on the front cover. After
the initial contact, tighten the set screw 1/8 to
1/4 turn more to set the bypass valve blade
into position. The set screw should now be
touching the stop plate on the front cover. This
will prevent the bypass valve blade from getting
stuck on the front cover casting. Remove the
bypass actuator set tool.
