7. SPECIFICATIONS
7. SPECIFICATIONS
AC Line Input:
DC Discharge
Current:
Timer
Digital
Meter Accuracy
Cooling:
Housing:
Outer Dimensions:
AC Line Cord:
DC Discharge
Cable:
Weight:
Fuses:
Modes:
115 volts ± 10%, 50/60Hz, 3 amperes or
230 volts ± 10%, 50/60Hz, 1.5 amperes
(selectable on rear of unit)
Capacity 0-50 amperes adjustable current
Accuracy < ± 2% from discharge initiation to cut-off
Setting Adjustable from 0 to 999.9 minutes
Accuracy < ± 0.1%
Voltmeter < ± 0.2 volts
Ammeter < ± 0.2 amperes
Fan cooled
Aluminum chassis
Height 14 in. (356 mm)
Depth 15 in. (381 mm)
Width 10 ¼ in. (260 mm)
AWG 16 3 wire grounded
6 ft long with 115 volt 15 ampere plug.
User required to change to 230 volt plug
4 ft long, with Aircraft battery connector
Net 33 lbs.
Shipping 38 lbs.
AC line fuse 3A/250V, type MDA 1 ¼ x ¼
DC line fuse 70AMAXI Fuse
Analysis (automatic cut-off) and deep
cycle (full discharge) with cutoff set to one
volt.
BETA D-50 TESTER / ANALYZER - OPERATING MANUAL V2.2 Page 29
