Product Service 1-800-522-7658 49
A A p p p p e e n n d d i i x x E E : :
L L i i f f e e S S p p a a n n f f o o r r O O x x y y g g e e n n R R e e m m o o v v a a l l
C C o o l l u u m m n n & & M M o o i i s s t t u u r r e e T T r r a a p p R R e e m m o o v v a a l l
Note: Precise Glove Box Volume is 13 cu. ft. or 368 liters; 3000ppm or 0.3% of 368 liters = 1.1 liters of oxygen initially used
Glove Box Initial Oxygen Catalog# 5244200 Total Oxygen Total Oxygen Number
Main Chamber Pressure Oxygen Leak Rate Capacity Used Oxygen Column Life Life Capacity Volume Capacity of Columns
(inches of water) (ppm/min) (ppm) (24 hour days) (ppm) (liters)
-1 0.52 3000 21 19022 7 1
0 0.22 3000 51 19022 7 1
1 0.15 3000 74 19022 7 1
Note: All data with glove port covers installed
Glove Box Catalog# 5244200 Total Moisture Total Moisture Number
Main Chamber Pressure Moisture Leak Rate Initial Moisture Moisture Column Life Life Capacity Weight Capacity of Columns
(inches of water) (ppm/min) (ppm) (24 hour days) (ppm) (grams of moisture)
-1 2.9 10000 3318 13864241 100 1
0 1.7 10000 5659 13864241 100 1
1 1.6 10000 6013 13864241 100 1
Note: 1ppm of moisture = 7.21ug of moisture inside the 368 liter glove box volume Note: All data with glove port covers installed
Glove Box Catalog# 7815200 Total Moisture Total Moisture Number
Main Chamber Pressure Moisture Leak Rate Initial Moisture Moisture Trap Life Life Capacity Weight Capacity of Traps
(inches of water) (ppm/min) (ppm) (24 hour days) (ppm) (grams of moisture)
-1 2.9 10000 4314 18023514 130 1
0 1.7 10000 7358 18023514 130 1
1 1.6 10000 7818 18023514 130 1
-1 2.9 10000 8630 36047028 260 2
0 1.7 10000 14721 36047028 260 2
1 1.6 10000 15641 36047028 260 2
Note: 1ppm of moisture = 7.21ug of moisture inside the 368 liter glove box volume Note: All data with glove port covers installed
