This Appendix contains technical information about the freeze dryer
including electrical specifications, environmental operating conditions and
wiring diagrams.
Electrical Specifications
Catalog #
Voltage
Frequency
Phase
Amperage
Nominal
Operating
Range
Nominal
w/o
Vacuum
Pump
Max. with
Vacuum
Pump
7386020
115V
103-127
60
1
11
16
100V
90-110
50
1
11
16
7386021
115V
103-127
60
1
11
16
100V
90-110
50
1
11
16
7386030
230V
198-254
50
1
5.5
10
7386031
230V
198-254
50
1
5.5
10
7386040
230V
187-253
60
1
5.5
10
7386041
230V
187-253
60
1
5.5
10
7386060
230V
198-254
50
1
5.5
10
7386061
230V
198-254
50
1
5.5
10
7386070
230V
198-254
50
1
5.5
10
7386071
230V
198-254
50
1
5.5
10
7387020
115V
103-127
60
1
11
16
100V
90-110
50
1
11
16
7387021
115V
103-127
60
1
11
16
100V
90-110
50
1
11
16
7387030
230V
198-254
50
1
5.5
10
7387031
230V
198-254
50
1
5.5
10
7387040
230V
187-253
60
1
5.5
10
7387041
230V
187-253
60
1
5.5
10
7387060
230V
198-254
50
1
5.5
10
7387061
230V
198-254
50
1
5.5
10
7387070
230V
198-254
50
1
5.5
10
7387071
230V
198-254
50
1
5.5
10
