11. Product overview
D SERIES Lake Quick Start Guide rev 1.2.0
13
Table 1 LED/category chart
NOTE: See Faults and warnings (pages 23-25) for a detailed description of status, faults and warnings associated
with each LED.
OFF
Green
Amber
Red
Frame
N/A
Frame OK
Frame warning
Frame fault
Temp
N/A
Temp OK
Temp warning
Temp fault
PSU
N/A
PSU OK
Power supply/
Mains warning
Power supply/
Mains fault
Power
No mains power
Fixed:ON
Blinking: Turning ON
Button pressed.
Hold for transition
Fixed: STANDBY
Blinking: Turning to
STANDBY
Load
No LoadPilot active
LoadPilot active
and LoadOK
Load warning
Load fault
Amp
N/A
Power channel OK
Power channel warning
Power channel fault
Signal
Signal below signal
present threshold (-60 dB)
Signal above signal
present threshold (-60 dB)
Signal approaching
input clip (-2 dB)
Signal clip
or limit/fault active
Mute
Inactive channel in
bridge operation
Unmuted
Lake module is muting the
signal chain at either input
router, module input or
module output
Power channel muted
Select
Frame not selected
Frame selected
Waiting for more touches
N/A
