Konig Electronic Camera and recorder in housing - Manual (Page 3)

3
ENGLISH
2. Open the folder and select DvXSet.exe to enter the settings.
• Date: Click on the year, month and date to set. Use
the up and down arrow button to adjust the settings.
• Time: Click on the hour, minute and second to set.
Use the up and down arrow button to adjust the
settings.
• Stamp Date Format: Select YY/MM/DD, DD/MM/YY
or MM/DD/YY. Use the arrow down button to adjust
the settings.
• Motion Detection Sensitivity: Select the sensitivity of
the motion detector from 1 to 5. Use the arrow down
button to adjust the setting. (5 is the most sensitive
setting, 3 is recommended).
• Light Frequency (Hz): Select the light frequency for
your country. For example, 50 Hz for Europe; 60 Hz for
United States. Use the arrow down button to select.
• Image Quality: Select the recording quality, High-HD, Standard or Low VGA. Use the arrow
down button to select.
• OverWrite: If the SD card must be overwritten when it is full, then select ON. If overwritten
is not preferred, then select OFF. Use the arrow down button to select.
• Bell: When you want to hear a peep sound, press the button on the remote control or
motion detector, then select ON. If not, then select OFF. Use the arrow down button to
select.
• After adjusting all settings, click on SAVE and then press the SET button on the back side of
the camera for 3 to 5 seconds to store the settings in the motion detector.
Operation
1. Insert a Micro SD Card (max. 32 GB).
2. Insert the power supply into DC plug of the DC cable. Switch the power on. The power
and standby indicator light up.
1. Power indicator 2. Standby indicator
