3
LED INDICATORS
LED status Description
Status Green flash Device status is working
Green RJ45 cable is plugged in
WAN LED
Green flash Data access
Green RJ45 cable is plugged in
LAN LED
Green flash Data access
Green Wi-Fi is on
Green flash Data access
Green fast flash Device is in WPS PBC mode
Wi-Fi LED
Dark green Wi-Fi is disabled
BUTTON DEFINITION
Description
WPS
1. When wireless is switched off, press and hold this button for about 1 second to
enable “wireless radio”.
2. When wireless is switched on, press and hold this button for about 1 second to
execute WPS function.
Reset Press and hold for 6 seconds to reset to default settings
