Aquatic Fitness System
2003 Owner’s Manual
Term (Cont.)
Definition
Heater
An 11kw 230v thermostatically controlled electric heater equipped
with a high-limit temperature safety shut-off switch. If the high-limit
safety switch trips, contact your authorized Aquatic Fitness
System Dealer. See the
information.
Jets
Return the water into the Aquatic Fitness System from the
equipment. The HydroTherapy Jets produce a turbulent flow of
water mixed with air to provide a concentrated body massage. The
Swim Jets produce a high volume flow to provide a rapid current for
swimming.
Light
Illuminates the Aquatic Fitness System vessel.
Load Sharing
When the circuit breaker size is smaller than the total power
needed to operate both the heater and the jet pump at the same
time, load sharing automatically turns off the heater when a jet
pump is turned onto high speed.
Lock-Ring
Mechanism that affixes filter cover to filter housing. To remove
cover, turn lock-ring counter-clockwise until it disengages with filter
housing. When replacing the filter cover, turn lock-wring clockwise
to firmly secure the cover.
Ozone Generator
A specialized ultraviolet light that changes oxygen into ozone for use
in the water sanitation process.
Pressure Switch
Safety device(s) that sends a signal to the electronic control system
that there is adequate water flow to turn the heater on.
Primary Pump
Produces water flow through the heater, filter, sanitation system
and the main jets in the Aquatic Fitness System. The primary
pump will operate automatically during filtration and heat cycles.
This pump can also be operated manually by depressing the “jets”
button on the Top Side Control which will allow you to choose
between two speeds
• Low speed for efficient water circulation during heating and
filtration modes, and for gentle jet resistance or massage
action.
• High speed for maximum jet action.
Pump Union
A removable fitting that connects the pump to the Aquatic Fitness
System’s plumbing.
Selector Valve
Located on the top edge of the Aquatic Fitness System or spa, it
diverts jet power from one area of the Aquatic Fitness System
or spa to another.
Serial Number
Please use the serial number in communication with your dealer.
Servicing Filter Element
To clean or replace the filter element, shut off power to the
Aquatic Fitness System, loosen the lock-ring, remove the filter
cover and pull the filter element from the filter housing. Depending
upon use, you may simply rinse the filter element with a garden
hose, or you may be required to soak the element in Filter Cleaner
Solution. Replace any worn or damaged filter elements. It is always
good practice to have a spare filter element, so that you can
perform cleaning at your convenience.
