Twister KIT
Part No. Description Material Dimensions
No. off
1 1 KIT building instructions Paper, 80 g / m² A4
2 1 Decal sheet, sheet 1 Printed self-adhesive film 700 x 330 mm
3 1 Decal sheet, sheet 1, registration markings Printed self-adhesive film 500 x 350 mm
4 1 L.H. fuselage shell Moulded Elapor foam Ready made
5 1 R.H. fuselage shell Moulded Elapor foam Ready made
6 1 Ducted fan hatch Moulded Elapor foam Ready made
7 1 L.H. fuselage nose section Moulded Elapor foam Ready made
8 1 R.H. fuselage nose section Moulded Elapor foam Ready made
9 1 Canopy Moulded Elapor foam Ready made
10 1 L.H. wing Moulded Elapor foam Ready made
11 1 R.H. wing Moulded Elapor foam Ready made
12 1 Tailplane Moulded Elapor foam Ready made
13 1 Fin Moulded Elapor foam Ready made
Small parts set
20
3 Velcro tape, hook Plastic 25 x 60 mm
21 3 Velcro tap, loop Plastic 25 x 60 mm
22 2 Latch catch Injection-moulded plastic Ready made
23 2 Latch tongue Injection-moulded plastic Ready made
24 4 Glue-fitting control surface horn Injection-moulded plastic Ready made
25 4 Swivel pushrod connector Metal Ready made, 6 mm Ø
26 4 Washer Metal M2
27 4 Nut Metal M2
28 4 Socket-head grubscrew Metal M3 x 3 mm
29 1 Allen key Metal 1.5 mm A/F
30 2 Aileron pushrod, one Z-bend Metal 1 Ø x 80 mm
31 1 Elevator pushrod, one Z-bend Metal 1 Ø x 110 mm
32 1 L.H. servo fairing Vacuum-moulded plastic Ready made
33 1 R.H. servo fairing Vacuum-moulded plastic Ready made
34 2 Ballast weight Steel ball, 9 g 13 mm Ø
Wire and tube set
40
1 Tubular spar GRP tube 8 Ø x 700 mm
41 3 Fuselage stiffener GRP rod 1.3 Ø x 250 mm
Ducted fan power set
50
1 DF69 RTR ducted fan with Himax A 2825-3600 Assembled and balanced Ready made
Make it your job to keep your models and your radio control
system in perfect order at all times. Check the correct charging
procedure for the batteries used in your RC set. Make use of all
sensible safety measures and precautions which are advised
for your system. An excellent source of practical accessories is
the MULTIPLEX main catalogue, as our products are designed
and manufactured exclusively by practising modellers for other
practising modellers.
Always fly with a responsible attitude. You may think that flying
low over other people’s heads is proof of your piloting skill; others
know better. The real expert does not need to prove himself in
such childish ways. Let other pilots know that this is what you
think too. Always fly in such a way that you do not endanger yourself or others. Bear in mind that even the best RC system in
the world is subject to outside interference. No matter how many
years of accident-free flying you have under your belt, you have
no idea what will happen in the next minute.
We - the MULTIPLEX team - wish you many hours of pleasure in
building and flying your new model. Happy landings!
MULTIPLEX Modellsport GmbH & Co. KG
Model Development Dept.
Klaus Michler
