HD CAN Module Programmer’s Guide (Windows)
All intellectual properties belongs to Hatteland Display AS
J2534_ERROR_CODE err ;
PASSTHRU_MSG * rxPassThruMsgPtr = rxPassThruMsg ;
J2534_RxStatus rxStatus ;
err = PassThruReadMsgs ( channel_1 , rxPassThruMsgPtr , msgNumPtr ,
timeout );
if ( err == STATUS_NOERROR )
{
if ( msgNum != 0 )
{
for ( unsigned int i = 0 ; i < msgNum ; i ++)
{
id = rxPassThruMsg [ i ]. Data [ 0 ] << 24 ;
id |= rxPassThruMsg [ i ]. Data [ 1 ] << 16 ;
id |= rxPassThruMsg [ i ]. Data [ 2 ] << 8 ;
id |= rxPassThruMsg [ i ]. Data [ 3 ] << 0 ;
cout << hex << uppercase ;
cout << "ID:" << setfill ( '0' ) << setw ( ID_BYTES_NUM
* 2 ) << id << "\t" ;
cout << "DLC:" << setfill ( '0' ) << setw ( 2 ) <<
( rxPassThruMsg [ i ]. DataSize - ID_BYTES_NUM ) << "\t" ;
cout << "MSG:" ;
for ( unsigned int j = ID_BYTES_NUM ; j <
rxPassThruMsg [ i ]. DataSize ; j ++)
{
cout << setfill ( '0' ) << setw ( 2 ) <<
( int ) rxPassThruMsg [ i ]. Data [ j ] << " " ;
}
cout << dec ;
cout << "\t" ;
cout << "TYPE:" ;
rxStatus . value = rxPassThruMsg [ i ]. RxStatus ;
if ( rxStatus . bits . Can29BitId == 0 )
{
cout << "STD" << endl ;
}
else
{
cout << "EXT" << endl ;
}
}
}
else
{
cout << "No message has been received" << endl ;
}
}
}
/**************************************************************************
**********//**
* @brief Function to Write Messages
***************************************************************************
************/
static void callPassThruWriteMsgs ()
{
unsigned int id = 0x10 ;
