2 Notes
The following registers must be set at boot to be able to use all functions:
Command Device
Address
R/#W Register
Address
Input Data output
AIPC_ CFG0_W 0x20 0 0x06 0xFF
AIPC_ CFG1_W* 0x20 0 0x07 0x8F
*All output pins are defined as high by default. To avoid any undesired behavior please set the output
level low before defining the pins as outputs.
3 Instruction to access SMBus (Ubuntu)
This instruction is showing how to access the introduced Registers on SMBus Device.
The test environment is Ubuntu 12.04 LTS 32bit.
1. Connect with Internet, and start with a terminal
2. Install i2c-tools (www.lm-sensors.org)
sudo apt-get install i2c-tools
3. Probe i2c Modules
sudo modprobe i2c-dev
sudo modprobe i2c-i801
4. Set value of output pins low (Sets AIPC_K2, AIPC_HS1 and AIPC_HS2 low)
sudo i2cset –y 6 0x20 0x03 0x00 b
5. Initialize the AIPC_CFG0_W and AIPC_CFG1_W
sudo i2cset –y 6 0x20 0x06 0xFF b
sudo i2cset –y 6 0x20 0x07 0x8F b
6. Then start configure the register according to the address in the previous list
Example:
 Read “BUZZER_EN”
sudo i2cget –y 6 0x48 0x28 b
 Write “BUZZER_EN”
sudo i2cset –y 6 0x48 0x28 0x01 b
4 Limitations
A delay of 100ms must be added after every command.
Failure to do so may cause the SMBus to lock up.
A full power cycle is required to recover the SMBus when locked.
