Revision History
Abbreviation
Abbreviation Description
Created Approved
Rev Date By Date By Description
1 21.01.2013 Morten Mæland First version
2 2013.09.20 Wei Jing 2013-09-25 Joakim
Emanuelsson -Device address correction 0x40->0x20
-Instruction to configure the WD register under
Linux (Ubuntu)
3 2013-12-03 André Kråkenes 2013-12-06 Wei Jing QAR121116: Added information on how to avoid
activating relays after CFG1=0x8F.
