Product Labeling
IND100077-146
Label Locations
Number ID and coloring based on “Label Size and Types“ table from previous page. All illustrations below is seen
from rear (and side where needed) with connectors facing down. Actual labels regarding its size and text orientation
vs product size is drawn in. Due to space restrictions on selected units, some labels will be rotated 90 degrees to fit
properly. The arrangement of labels may be shifted/stacked differently as it is based on factory options, such as; Touch
Screen, but they will be grouped together where possible.
Label Positions Notes Applies for Product Range
Warranty label covers both
screw and bends over edge
(rear/side). Labels placed on
rear and side.
HD 08T21 STD-xxx-Fxxx
Warranty label covers screw.
Labels placed on rear and
side.
HD 13T21 STD-xxx-Fxxx
