Hanna Instruments HI 96716 - Manual (Page 5)

5
Range 0.00 to 10.00 mg/L
Resolution 0.01 mg/L
Accuracy ±0.08 mg/L ±3% of reading @ 25°C
Typical EMC Deviation ±0.01 mg/L
Light Source Tungsten lamp
Light Detector Silicon Photocell with narrow band interference filter @ 525nm
Method Adaptation of the Standard Methods for the Examination of Water and
Wastewater, 20
th edition, DPD method. The reaction between bromine
and the reagent causes a pink tint in the sample.
Environment 0 to 50°C (32 to 122°F); max 95% RH non-condensing
Battery Type 1 x 9 volt
Auto-Shut off After 10' of non-use in measurement mode ;
after 1 hour of non-use in calibration mode ;
with last reading reminder.
Dimensions 192 x 104 x 69 mm (7.6 x 4.1 x 2.7")
Weight 360 g (12.7 oz.).
REQUIRED REAGENTS
Code
Description Quantity/test
HI 93716-0 DPD Powder Reagent 1 packet
Precision is how closely repeated measurements
agree with each other. Precision is usually
expressed as standard deviation (SD).
Accuracy
is defined as the nearness of a test
result to the true value.
Although good precision suggests good accuracy,
precise results can be inaccurate. The figure
explains these definitions.
In a laboratory using a standard solution of
2.00 mg/L bromine and a representative lot of
reagent, an operator obtained with a single
instrument a standard deviation of 0.06 mg/L.
SPECIFICATIONS
PRECISION AND ACCURACY
