4
Front Panel
Rear Panel
1) Liquid Crystal Display (LCD).
2) CAL key, to enter and exit calibration mode.
3) CFM/GLP key, to confirm different values or to display Good
Laboratory Practice information.
4) ºC key, to manually increase temperature value or other parameters.
5) ºC key, to manually decrease temperature value or other parameters.
6) SETUP key, to enter/exit SETUP mode.
7) RANGE key, to select measurement range or to toggle between the
buffer value and temperature during calibration or to change the
focused data in setup (HI 2213 only).
key, to toggle between the buffer value and temperature during
calibration or to change the focused data in setup (HI 2212 only).
8) MEM key, to store a value into memory.
9) MR key, memory recall.
10) ON/OFF switch.
11) Power supply socket.
12) BNC electrode connector.
13) Temperature probe socket.
14) Electrode reference socket.
F U N C T I O N A L D E S C R I P T I O N F U N C T I O N A L D E S C R I P T I O N F U N C T I O N A L D E S C R I P T I O N F U N C T I O N A L D E S C R I P T I O N F U N C T I O N A L D E S C R I P T I O N
HI 2212 AND HI 2213 HI 2212 AND HI 2213 HI 2212 AND HI 2213 HI 2212 AND HI 2213 HI 2212 AND HI 2213
