4 5
V. V. V. V. V. Equipment Required: Equipment Required: Equipment Required: Equipment Required: Equipment Required:
•
HI 4014 requires the Hanna HI 5315 Double Junction
reference electrode with HI 7076 as external electro-
lyte.
•
Hanna HI 4222 pH/ISE/mV meter or other suitable
ion or pH/mV meter. (Note: log/linear graph paper is
useful if an ISE (ion) meter is not available).
•
Hanna HI 180 magnetic stirrer or equivalent with
magnetic stirring bars (Note: Isolate beakers from stir-
rer motor heat by placing insulating material such as
foam or cork between them).
•
Hanna HI 76404 electrode holder or equivalent.
•
Plastic beakers ( HI 740036P) or other suitable mea-
surement vessel.
VI. VI. VI. VI. VI. Solutions Required for P Solutions Required for P Solutions Required for P Solutions Required for P Solutions Required for Potassium Measure- otassium Measure- otassium Measure- otassium Measure- otassium Measure-
ments ments ments ments ments
0.1 M potassium standard, 500 mL HI 4014-01 HI 4014-01 HI 4014-01 HI 4014-01 HI 4014-01
Ionic Strength Adjuster, 500 mL HI 4014-00 HI 4014-00 HI 4014-00 HI 4014-00 HI 4014-00
Using volumetric pipettes and glassware make dilutions to
bracket the concentration of the samples. Standards with
concentrations <10
-3 M should be prepared daily.
Store standards in plastic bottles. Add 2 mL of Hanna ISA
HI 4014-00 to 100 mL sample or standard.
IV. IV. IV. IV. IV. Design elements of the HI 4014 and HI 4114 Design elements of the HI 4014 and HI 4114 Design elements of the HI 4014 and HI 4114 Design elements of the HI 4014 and HI 4114 Design elements of the HI 4014 and HI 4114
electrodes electrodes electrodes electrodes electrodes
SENSO
R
HANDLE
HI
4000-50
Cap
Sensing
module
Sensor
Handle
O-Ring
Upper Cap
Spring
O-Ring
Ceramic Junction
on Inner Stem
Fill Hole
O-Ring and
Plug
Sensing Module
Outer Sleeve
Upper
Threads
Liquid junction
