16
TV-to-VGA / HDTV Video Scaler
6. Specifications
Computer Input (Pass Thru) RGB with HV Sync
Max Computer Input
Resolution
1280x1024 (Scaled Output)
1920x1440 (Pass Thru)
Computer Input Connector HD-15 Female (DB-15)
Computer Input Signal Level RGB @ 0.7V Analog, H&V Sync TTL
Video Inputs
Composite Video
S-Video
Y
Pb
Pr
1 Vp-p 75 ohm
1 Vp-p 75 ohm
1Vp-p 75 ohm
0.7 Vp-p 75 Ohm
0.7 Vp-p 75 Ohm
(TVB-400A Only)
Audio Inputs
Audio Output
2 Vp-p max stereo line-level into a 10k impedance
Line level output with volume adjustment
Video Standard
PC: RGBHV - VGA(640x480) to UXGA(1600x1200)
SDTV: NTSC 3.58, PAL, B/D/G/I, SECAM
HDTV: 480i/p, 576i/p, 720p, 1080i/p
Video Input Connectors
Composite Video on BNC
S-Video on 4 pin Mini-DIN
YPbPr on 3 BNC
PC on VGA (HD15 Female)
Pixels Format Scan
PC
VGA 640x480
SVGA 800x600
XGA 1024x768
SXGA 1280x1024 RGBHV
RGBHV
RGBHV
RGBHV Progressive
Progressive
Progressive
Progressive
Scaled Output
Resolutions
HDTV
16:9 1280x720p (720p)
16:9 1920x1080i (1080i)
852x480p (480p)
852x576p (576p)
YPbPr
YPbPr
YPbPr
YPbPr
Progressive
Interlaced
Progressive
Progressive
Output Resolution Vertical (Hz) Horizontal (Hz)
Scaled Output Horizontal &
Vertical Refresh Rates
VGA
SVGA
XGA
SXGA
480p
576p
720p
1080i
59.94
60.320
60.000
60.020
59.940
50
59.94
59.94
31.469
37.880
48.360
63.981
31.469
31.25
44.995
33.716
Manual Control Front Panel Buttons
RS-232 Control Rear Panel DB-9 Female
IR Remote Control YES
Adjustments
Brightness, Contrast, Color Saturation, Tint
(NTSC), Sharpness, Volume (TVB-400A Only)
Weight 3 Lbs
Dimensions 8 inch (W) x 6 inch (D) x 1.83 inch (H)
Power Source
100-240 VAC to DC 5V/2A Desktop Switching
Adapter
