Model SC-1080D
7
VGA: The output resolution will be a PC compatible (VGA to WUXGA)
RGBHV
Note about HDCP
signal.
For HDMI™ compliance, if the input is from an HDMI™ source with content
protection, the VGA output is blanked and front panel LED blinks.
DVI: This is the TMDS digital output of the Scaler. You can connect this to any
PC compatible LCD with a DVI compatible connector input, or any HDTV with
a HDMI™ compatible connector input using the appropriate cable.
2.2 Other Connections
RS232: This 9-pin D-sub connector is for connecting to your PC or other serial
control device for remote control of the SC-1080D.
Scaler Interconnect Cable DB9 M/F Remote Controller
PIN Definition PIN Definition
2 TxD 2 RxD
3 RxD 3 TxD
5 GND 5 GND
AC power jack: This is a standard IEC320 / C14 power connection. The unit’s
power supply is universal (90 ~ 264 VAC, 50 ~ 60 Hz).
Video Outputs
