Hall Research VHD-180 - Manual (Page 9)

PC / HDTV to TV Scan Converter
7
2.4 IR Remote Controls
1. Power ON/OFF
2. Video setting adjustments for picture
contrast, bright, color and sharpness.
3. V-Reset: Press the button to reset
picture adjustment (2) to factory default
values.
4. NTSC/PAL: Press the button to select
NTSC or PAL as video output.
5. Color bar pattern ON/Off
6. Image freeze ON/Off
7. Output format: Press the button to
select your desired output format.
Toggles between CV/SV & YCbCr
8. Under/Over Scan: Press to enlarge or
shrink the image on output
9. Region selection (Zoom): Under zoom mode press one of the
buttons to select its corresponding sub-area.
10. Zoom ON/Off: Press the button to zoom in on a picture, press again
to zoom out.
11. Horizontal/Vertical Adjust: Adjust the size or position of an image
when it is under Zoom, Pan/Position, or Size/EXP mode.
12. Default: Press the button to revert the following parameters to
factory preset values: Zoom, Position, Size, and Picture Adjust
13. Pos/Pan: When a picture is in Underscan mode, press the button to
do position adjustment. When a picture is in Overscan mode, press
the button to do pan adjustment.
14. System reset: Press the button to revert all system parameters back
to factory preset values. The system parameters are default as
follows: Overscan, NTSC output, Full aspect, Video settings Reset,
Position, Pan, Size and Expand reset.
15. Size/EXP: When a picture is in Underscan mode, press the button
to do size adjustment. When a picture is in Overscan mode, press
the button to do expand adjustment.
16. Aspect: Press the button to switch between full, Pan & Scan or
letterbox.
