7
Model SKU-RGB
4. Troubleshooting
4.1 Contacting Hall Research
If you determine that your unit is malfunctioning, do not attempt to repair the unit. The unit contains
no user serviceable equipment. Opening the unit will void the warranty. Contact the Hall Research
Technical Support department at 714-641-6607 to obtain a RMA (Return Authorization) number.
Before you do, make a record of the history of the problem. We will be able to provide more
efficient and accurate assistance if you have a complete description.
4.2 Shipping and Packaging
If you need to transport or ship your unit, pack it carefully (original container recommended) and
contact Hall Research for a Return Authorization (RMA) number.
5. Specifications
Video Specs:
• Connectors: Input and Outputs: HD15 female
• Coupling: DC
• Signal Level: Video: 0.7 v p-p
• Bandwidth: 150 MHz
• Resolution: Up to 1600 x 1200
• Input Impedance: 75 ohms on RGB
• Supported Signals: VGA, RGBHV, and YPbPr via HD-15
Dimensions:
2.75 W x 1.1 H x 3.1 D inch
Weight:
0.5 Pounds
Power (included):
UL approved 120 V ac adapter
6 vDC @ 300 mADC output, 2.5mm center positive
Operating Temperature: 32 to 122 degF (0 to 50 degC) – 10%-90% Non-Condensing
Storage Temperature:
14 to 176 degF (-10 to 80 degC) – 10%-90% Non-Condensing
