KVM EXTENSION OVER UTP FOR DUAL VIDEO PC’s
5
3. Connect the audio output from the PC to the audio input on the
Sender via the “INPUT” label on the Sender unit with a male-to-
male mini-stereo cable
4. Connect the RS-232 (serial) output from the PC to the RS-232
input on the Sender via the “RS-232” label on the Sender unit with
a male-to-female DB9 cable
5. Connect any combination of keyboard, mice, video A, video B,
audio, or RS-232 to the Sender and Receiver to control the PC
a.
Connect a keyboard and/or mouse and/or video and/or
audio and/or RS-232 to the Sender unit via the connections
labeled “Local” if local control is desired.
b. Connect a keyboard and/or mouse and/or video and/or
audio and/or RS-232 to the Receiver unit if remote control
is desired.
NOTE: The Receiver does not have to be connected to use the
Local station
NOTE: The Sender does not have to have a local keyboard or a
local mouse connected for the Receiver to function
6. Connect the Sender and the Receiver units with a Catx cable
a.
NOTE: Port A of the UTP carries the keyboard, mouse,
audio, RS-232 handshake lines and video channel A.
b. NOTE: Port B of the UTP carries the video channel B and
the RS-232 TX and RX lines
7. Power on the Receiver unit with the supplied power supply (GS-
385)
8. Power on the PC.
