User’s Manual
6
7. Specifications
Input Port 1x HDMI Female Locking Connector (Type A)
Output Port 4x HDMI Female Locking Connector (Type A)
Connectors Locking HDMI
Video Resolutions Output resolution is same as input resolution.
PC Resolutions : VGA - SVGA – XGA – SXGA – UXGA -WUXGA
HDTV Resolutions : 480i - 480p - 720p - 1080i - 1080p, 4Kx2K@30
Bandwidth 10.2 Gbps total (or 3.4 Gbps per color, or 340 MHz TMDS clock)
Video Standards HDMI 1.4 (for 3D, Deep-Color & 4Kx2K), HDCP1.1 and DVI1.0
Audio Formats All HDMI Embedded Audio including: LPCM 7.1CH, Dolby TrueHD and
DTS-HD Master Audio (32-192kHz sample rate)
Power Supply 100-240 VAC, 50-60 Hz, external; +5 V DC, 2.6 A DC, 13 Watts, Center-
Positive, Locking 2.1mm ID Connector
Actual Power Consumption: 110 mA ~ 475 mA (or 0.55 ~ 2.4 watts)
depending on # outputs plugged in at 1080P
Temperature/humidity Storage: -40 to +185 °F (-40 to +85°C) / 10% to 90%, non-condensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, non-condensing
Mounting End plates have L bracket with holes for surface mounting
Enclosure type Metal (Steel ends and Aluminum extrusion)
Dimensions 1.5" H x 5.6" W x 4.1" D
(38mm H x 142mm W x 105mm D)
Product weight Product - 0.85 lb (0.386kg)
Shipping - 1.5lbs (0.681 kg)
Safety CE
EMI/EMC CE, FCC Class A
MTBF 90,000 hours (Calculated Estimate)
Warranty 2 years parts and labor
Specifications are subject to change without notice
Note: When displaying an HDMI signal with a higher bandwidth than 225
MHz (such as 1080p deep-color, or 4K×2K video), a High Speed HDMI
cable is required.
