Specifications – Hall Research 210-LU User Manual

Page 4

210-LU

Specifications

Analog inputs:

3 BNC type labeled RED, GREEN, and BLUE

Input impedance: 75 ohm, voltage level: 3 vp-p max, 1 vp-p nominal

Sync inputs:

2 BNC type labeled HOR, VERT

Input impedance: 2 k ohm, voltage level: 0 - 5 v max, TTL

Analog outputs:

2 independent channels, 3 BNC's each

Output

impedance:

ohm,

short

circuit

protected, level: 1 vp-p nominal with termination

SYNC outputs:

2 TTL line driver BNC outputs per channel

Level:

TTL

compatible

Video amplifier:

Greater than 300 Megahertz bandwidth, DC coupled

Composite sync:

TTL on the HOR output, or sync-on-green depending on switch position

Comp sync polarity:

Negative

Input power:

6vDC grounded adapter supplied (range 6 ~ 9 VDC). OR +5v DC grounded regulated power supply
on Molex connector.

Power consumption:

1.2 watts maximum

Physical: 8.88 x 3.13 x 1.35 inch (excluding connectors & mounting bracket) - weight: 1.2 lb

Federal Communications Commission Statement

This equipment can generate, use and radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. This equipment has been designed to comply with the
limits for a Class A computing device, pursuant to Part 15 of the FCC rules. Harmful interference when operated in a
commercial environment. Operation of this equipment in a residential area is likely to cause interference, in which case the
user, at their own expense, will be required to take whatever measures are necessary to correct the interference.

Warranty

HRT warrants that the supplied equipment is free from defective workmanship and material. Subject to the
agreements set forth, will repair or replace, at its option, the defective components for a period of 2 years after
purchase. The following conditions apply to the Warranty:

•

Warranty void if item subject to improper use, negligence, or unauthorized modification

•

Instructions must be followed in obtaining RMA number as explained below

•

Any defective part should be returned, insured and freight prepaid, to Hall Research, with the following:

Return Material Authorization Number (RMA#)
Description of failure, as detailed as possible
Shipping address and contact name and phone number

1163 Warner Ave., Tustin, CA 92780
Ph: (714)641-6607, Fax: (714)641-6698
