Compact CAT5 Video/RS232 Splitters and Receivers
11
4.2 Calling Hall Research
If you determine that your splitter is malfunctioning, do not attempt to
repair the unit. Contact Hall Research Technical Support at 714-641-
6607. Before you do, make a record of the history of the problem. We
will be able to provide more efficient and accurate assistance if you
have a complete description.
4.3 Shipping and Packaging
If you need to transport or ship your Splitter: Package it carefully (we
recommend that you use the original container), and before you ship
the unit back to Hall Research for repair or return, contact us to get a
Return Material Authorization (RMA) number.
5. Specifications
Supported
Video Types
VGA through UXGA, RGBS, or RGB
Can also transmit Composite Video (CV), S-Video (Y/C), and
Component Video (Y, Pb, Pr) on pins 1, 2, and 3 of the HD15 VGA
connector (adaptor cable may be needed)
Resolution &
Refresh Rate
Up to 1600 x 1280 non-interlaced at up to 85 Hz
Bandwidth
Video: DC to 250 MHz
Video Level
0.7 volts peak-to-peak
RS232
Transmission Local output: Bidirectional, Remote: Unidirectional (Tx from
Sender)
Maximum
Distance
Up to 1000 ft. (305 meters) – See table 3.1 for details
Connectors
HD15 female for video input and output
3.5 mm Mini-Stereo for RS232 input and output
RJ45 for CAT5 outputs
Compliance
CE; FCC Part 15 Subpart B Class A, IC Class
