U2-160-DP
4
3. Troubleshooting
If host PC fails to detect USB device, check the LED status on
the local and remote units. Make sure LEDs are illuminated.
CAT6 cable is recommended particularly if the length is longer
than 100 ft. Reboot the Host PC. Unplug the local unit from the
Host PC and connect it to a different USB port if available.
There are no field serviceable parts or circuits in the device.
Opening the device will void the warranty. If you think the
device is malfunctioning, please contact Hall Research.
4. Specifications
Local Unit
Upstream Port USB Type B Female
Downstream Port RJ 45 Jack
Power Bus Powered
Remote Unit
Downstream Port USB Type A Female
Power External 5V Supply
Dimensions
Local:
4.5 x 2.7 x 1.8 inch (114 x 69 x 46mm)
Remote:
2.6 x 1.4 x 0.8 inch (66 x 36 x 20 mm)
Interconnect
Cable
Standard category 5e/6 UTP or STP
CAT6 Recommended
Max Cable
Length
50 m (164 ft)
Power Supply
Universal AC input, 5vDC @ 2A output
Hall Research P/N 511-PA1015-1L
Operating
Temperature
32 to 150 °F (0 to 65 °C)
