59
5
Accessories
Installing the Label Roll Module on the Printer
1. Pass the labels through the guides and the cutter.
2. Close the top cover and printing mechanism. To finish, press the FEED button to set the label position.
Close the top cover
Push
1
RELEASE CATCH
Release catch for closing
the printer cover
2
Press the feed key
* *** We advise against using inside wound label stock.
** ** Labels should be at least 30 mm high. When using the printer with the cutter, you should set the stop position
(^E) to 30.
Through the label guides
Through the cutter
