Glow-worm Clearly Solar Vertical On-Roof Collector User Manual
Page 8
8
3 Solar Collector and Hydraulic Connection Arrangement
1
4
5
...
1
12
11
2
...
Diagram 3.1
15025
14915
6 and up to 12 max Collectors
THE HYDRAULIC FLOW MUST BE DIAGONAL
1-5 Collectors
THE HYDRAULIC FLOW CAN BE DIAGONAL OR TOP AND BOTTOM
Solar Collector
The recommended collector arrangements are shown below.
Hydraulic Connections
It is recommended that the hydraulic connections should be
made as shown below.
1
4
5
...
TOP & BOTTOM
DIAGONAL
DIAGONAL
