FeiYu Tech FY-AHRS-2000B User Manual
Page 4
Guilin Feiyu Electronic Technology Co., Ltd
Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyudz.cn [email protected]
- 3 -
1. Dimensions and Interface Description:
Dimensions：
Interface：
2. Performance Parameter
Specification
FY-AHRS-2000B Remark
Performance
Refresh Rate（Hz）
1~100
The default refresh rate is 20Hz
Initialization Time（sec）
3
Heading
Output Range（deg）
0~360
length（mm）
width（mm）
height（mm）
45
25
11
Black cable Red cable Yellow cable
Green cable
GND
+5V
RX
TX
