FY-AHRS-2000B attitude configure command example:
$Config,9,1 (CRLF)
Open the FY-AHRS-2000B serial data output
$Config,4,16 (CRLF)
Configure the FY-AHRS-2000B magnetic field deviation angle of 16 degrees.
$Config,99,1(CRLF)
Write the configuration information to the FLASH.
Attention: If there is any change of the configuration parameters, you must click "Write
FLASH" button, or choose menu "configuration"->"permanent preserve configuration
parameters", to write the configuration to FLASH and permanent preserve, or next time
power up, these configuration parameter will be lost.
——END——
Note: We reserve the right to change this manual at any time! And the newest edition will
be shown on our website www.feiyudz.cn.
calibration
write the
configuration
information
in the FLASH
$Config 99 It is fixed at 1
Once configured,
send this command
to write the
configuration
information in the
FLASH
NULL NULL NULL
