II. As following, “Tool” interface:
Fig7 Parameters setting --“Tool” Interface
Attention: If you select the button, click the right mouse button you can
cancel the operation, changes to a hand type mouse.
III. Please click the set button, after set a parameter. As following, “Param1”
interface:
Fig8 Parameters setting --“Param1” Interface
①
②
PID
Control Parameter description
Turn ctrl P、I、D turn control
parameters
Height
ctrl P、I、D Height control
parameters
Throttle
ctrl P、I、D Throttle control
parameters
Route
stability P、I、D Route stability
parameters
Pitch
stability P、I、D Pitch stability
parameters
Roll
stability P、I、D Roll stability
paramenters
Flight
parameters Function description
TGT SPD Target Speed, set the
expectations value of the
current speed, unit: km /
h
TGT ALT Target Altitude, set the
expectations value of the
current altitude, unit: m
CIR RAD Circle Radius, set the
circling radius, unit: m
PHOLNTVAL Photographic Interval, set
the space distance or time
between every automatic
photography. Unit: m.
when in Timing take
photo then the unit is: s.
Cruise thr set the throttle control
neutral value of the Panda
autopilot ,this value only
activated when the plane
is in automatic navigation
fighting. This value can be
auto record when grab
the servo neutral value.
PG delay Photographic delay, set
the interval time between
trigger the shutter and
completely save the
