EZ-ACCESS PATHWA MODULAR ACCESS SYSTEM - Manual (Page 5)

- 5 -
UNIVERSAL PLATFORM (STRAIGHT CONFIGURATION) UNIVERSAL PLATFORM (TURN CONFIGURATION)
MPPC – CONNECTOR – PLATFORM TO PLATFORM MHRRRC – CONNECTOR – RAMP HR TO RAMP HR
MHRPRC – CONNECTOR – PLATFORM HR TO RAMP HR MBP36, MBP48, MBP60 - BRIDGE PLATE
MSTSXXPR - FEET & SUPPORT TUBE PAIRS MHREC - HANDRAIL END CAP
ITEMS NOT SHOWN ACTUAL SIZE
XX DENOTES USABLE LENGTH (LENGTHS
AVAILABLE 10” THROUGH 100")
